More than 6 hours backup power available.
Less than 20ms switch time.
Supports 100% unbalanced three-phase output.
Color LCD screen.
Bulk pricing, availability, and technical support for installers & dealers.
| Model | H3-80-Plus-US-H | H3-100-Plus-US-H | H3-125-Plus-US-H | H3-150-Plus-US-H |
|---|---|---|---|---|
| PV INPUT | ||||
| Max. Array Power [kW] | 160 | 200 | 250 | 272 |
| Max. Input Power [kW] | 160 | 200 | 250 | 272 |
| Withstand Voltage [V] | 1000 | |||
| Input Voltage Range [V] | 180 – 950 | |||
| Max. MPPT Input Current [A] | 40 | |||
| Max. MPPT Short Circuit Current [A] | 50 | |||
| MPPT Voltage Range [V] | 180 – 850 | |||
| Start-up Voltage [V] | 180 | |||
| No. of MPPT Trackers | 8 | |||
| Strings per MPPT Tracker | 2 | |||
| BATTERY SPECIFICATION | ||||
| Battery Type | LFP (LiFePO4) | |||
| Voltage Range [V] | 180 – 950 | |||
| Max. Charging/Discharging Current [A] | 240 (80+80+80) | |||
| Battery Port | 3 | |||
| Communication | CAN*3 | |||
| AC OUTPUT (GRID) | ||||
| Nominal AC Power [kW] | 80 | 100 | 125 | 150 |
| Max. AC Output Power [kVA] | 80 | 100 | 125 | 150 |
| Nominal AC Output Current [A] | 96.2 | 120.3 | 150.4 | 180.4 |
| Max. AC Output Current [A] | 96.2 | 120.3 | 150.4 | 180.4 |
| Nominal AC Voltage [V] | 480, 3W+N+PE or 3W+PE | |||
| Nominal AC Frequency [Hz] | 50/60 | |||
| Frequency Range [Hz] | 45 – 55 / 55 – 65 | |||
| Power Factor | 0.8 Leading – 0.8 Lagging | |||
| Max. THDi [%] | <3 @Rated Power | |||
| AC INPUT (GRID/GENERATOR) | ||||
| Max. AC Input Power [kW] | 249.4 | |||
| Max. Bypass Current [A] | 300 | |||
| Nominal AC Voltage [V] | 480, 3W+N+PE or 3W+PE | |||
| Frequency Range [Hz] | 50/60, ±5 | |||
| EPS OUTPUT (LOAD) | ||||
| Max. AC Output Power [kVA] | 80 | 100 | 125 | 150 |
| Peak AC Output Power [kW] (10s) | 187 | |||
| LRA Current [A] | 300 | |||
| Nominal AC Voltage [V] | 480, 3W+N+PE or 3W+PE | |||
| Nominal AC Frequency [Hz] | 50/60 | |||
| Switching Time [ms] | <20 | |||
| THDV [%] | <3 @Rated Power | |||
| EFFICIENCY | ||||
| CEC Efficiency [%] | 97.6 | |||
| Max. Efficiency [%] | 98.2 | |||
| PROTECTION | ||||
| DC Input Switch | Yes | |||
| Battery Reverse Polarity | Yes | |||
| PV Reverse Polarity | Yes | |||
| AC Overcurrent Protection | Yes | |||
| AC Output Short Circuit Protection | Yes | |||
| AC/DC Surge Protection | Class II | |||
| ISO Detection | Yes | |||
| Residual Current Detection | Yes | |||
| Ground Fault Detection | Yes | |||
| AFCI | Yes | |||
| Terminal Overtemperature Protection | Yes | |||
| String Current Detection | Yes | |||
| GENERAL SPECIFICATION | ||||
| Dimensions (W*H*D) [in / mm] | 28.74*41.73*12.01 / 730*1060*305 | |||
| Weight [lbs / kg] | 264.6 / 120 | |||
| Operating Temperature [°F / °C] | -22 – 140 / -30 – 60 | |||
| Cooling Method | Smart Air Cooling | |||
| Operating Altitude [ft / m] | 6561 / 2000 | |||
| Humidity [%] | 0 – 100 | |||
| Noise [dB] | <70 | |||
| Standby Consumption [W] | <60 | |||
| DC-Link EV Charger Ready [kW] | 20 – 50 | |||
| Ingress Protection (IP) Rating | NEMA 4X | |||
| Topology | Non-isolation | |||
| Display | LED, LCD, Wi-Fi+APP | |||
| Communication Ports | USB / RS485 / Bluetooth / Wi-Fi+LAN / 4G(Optional) / CAN | |||
